LED
● Per unit: Power 1 (Green), Power 2 (Green), P-Fail
(Red)
● Ethernet port: Link/Activity (Green)
Operating Humidity
● 5% ~ 95% (Non-condensing)
Operating Temperature
● -40°C~75°C / -40°F~167°F(-E model)
Storage Temperature
● -40°C~85°C / -40°F~185°F
Power Supply
9V~36VDC
● PoE Budget 100W at 24V input; 80W at 12V input
● PoE pin assignment RJ-45 port # 1~#16 support IEEE 802.3at/af
● End-point, Alternative A mode. Per port provides up to 30W.
● Positive (VCC+): RJ-45 pin 1,2
● Negative (VCC-): RJ-45 pin 3,6
Power Consumption
● 15W exclude PoE loads(100W)
● Galvanic Isolation Between power input and system/case ground
● Between Ethernet port and system/case ground
● Between power input and Ethernet port
Case Dimension
● Metal case IP-30
● 74 (W) x 105 (D) x 152 (H) mm
Weight
● 900 g
Installation
● DIN Rail and Wall Mount** Design
Relay Alarm
● Provides one relay output for power fail and alarm.
● Alarm Relay current carry ability: 1A @ DC24V
EMI & EMS
● FCC Class A, CE EN55011,
● CE EN55032, CE EN55024,
● CE EN61000-4-2, CE EN61000-4-3,
● CE EN61000-4-4, CE EN61000-4-5,
● CE EN61000-4-6, CE EN61000-4-8,
● CE EN61000-6-2, CE EN61000-6-4
