VGA
1 x VGA
VGA: resolution up to 1920x1200 @ 60Hz
DisplayPort/HDMI
2 x HDMI/DP++ (auto detection)
HDMI: resolution up to 4096x2160 @ 30Hz
DP++: resolution up to 4096x2304 @ 60Hz
Chipset
Intel® UHD Graphics 770
Uitbreidingsmogelijkheden
Uitbreiding slots
M.2
1 x M.2 2230 E key (PCIe/USB 2.0)
1 x M.2 3042/3052 B key (PCIe/USB3.0)
Poorten & Interfaces
LAN poorten
2
Seriele poorten
6
USB 2.0 poorten
2
USB 3.x poorten
4
Audio interface
1 x Line-out, 1 x Mic-in
Externe I/O
LAN
2 x GbE (RJ-45)
Serial
2 x RS-232 (DB-9)
4 x RS-232/422/485 (DB-9)
USB
2 x USB 2.0 (type A)
4 x USB 3.1 (type A)
Digital I/O
DIO 8 bit (DB-9)
Opslag
RAID
0, 1
Opslag interface
M.2
1 x M.2 2280 M key (PCIe x4 NVMe/SATA)
2.5"
2 x 2.5" SATA 3.0 Drive Bay
support RAID 0/1 (Q670E/R680E)
Mechanische specificaties
Afmetingen
255.3 x 85 x 224mm
Montage
Wall Mount
Product eigenschappen
Gewicht
4.15 kg
Electrische specificaties
Input range
Wide range 9~36V
Omgeving specificatie
Opslag temperatuur
-20/+85°C
Operating Temperatuur
-20°C/+70°C
Relatieve luchtvochtigheid
5 to 95% RH (non-condensing)
Certificeringen
standaarden
Shock
Half sine wave 3G, 11ms, 3 shock per axis
Vibration
IEC68-2-64
