• Fanless Intel Skylake-U / Kaby Lake-U 15W Processors
• Embedded Long-life Series, Planned Lifecycle Through Q3’2030
• Supports DDR4-2133 up to 32GB Total Memory
• 2 X Intel Gigabit LAN, HDMI + VGA
• 1 X 2.5” SATA Storage Bay & 1 X mSATA Slot
• ECO-design for EuP/ErP
Uitbreidingsmogelijkheden
Uitbreiding slots
1 X Mini-PCI Express Slot (Half-size)
Poorten & Interfaces
LAN poorten
2
Audio interface
Realtek ALC662VD HD Audio
Externe I/O
• 2 X USB 3.0 ports
• 2 X USB 2.0 ports
• 1 X VGA
• 1 X SIM Slot
• 1 X Power LED
• 1 X HDD LED
• 1 X On/Off Power Button
• 1 X +12V 2.5mm Diameter DC Power Jack
• 1 X HDMI (4096 * 2304 @ 24Hz)
• 2 X USB 3.0 ports
• 2 X USB 2.0 ports
• 2 X RJ-45 LAN ports
• 1 X Line-out/Mic Combo Jack
• 1 X Line-in Jack
• 2 X WiFi Antenna Holes
Opslag
Opslag interface
• 1 X SATA3 6Gb/s Connector
• 1 X mSATA/Mini-PCIE Shared Slot (Full-size)
Mechanische specificaties
Afmetingen
116.9 (W) x 144 (D) x 65 (H) mm
Electrische specificaties
Input range
12 V DC
Power consumption
40 W
Omgeving specificatie
Opslag temperatuur
-10°C ~ 70°C
Operating Temperatuur
0°C/+50°C
Certificeringen
standaarden
• CE,FCC,ErP For Barebone
• CE,FCC,TUV,UL,CCC,CB,ErP For Power Adapter
