LTE Cat4 v1 router with 2GE & GNSS & IO, EMEA
LTE Cat4 v1 router with 2GE & GNSS & IO, EMEA
Neem contact met ons op voor de levertijd
Details
Specificaties
Downloads
Specificaties
-
Processor
| Processor | ARM |
|---|
| Basisfrequentie | 1.2GHz |
|---|
| Aantal cores | 4 |
|---|
-
Geheugen
-
Belangrijkste eigenschappen
| Kenmerken | • LTE Cat.4 with 3G/2G fallback
• 2 × SIM for redundancy
• 2 × Ethernet 10/100/1000 Mbps
• 1 × RS232 + 1 × RS485 + 1 × DI +1 × DO
• WiFi 5, IEEE802.11ac
• Wide operational temperature range
• Wall-mount design and optional Din-Rail kits
• Linux based OS & SW customization
• Compact and ruggedized design |
|---|
-
Poorten & Interfaces
| GNSS | Yes |
|---|
| LAN poorten | 2 |
|---|
| Seriele poorten | 2 |
|---|
| Externe I/O | LAN
2x Ethernet 10/100/1000 Mbps
Serial
1× RS232
1× RS485
Digital I/O
1× Digital input (dry contact)
1× Digital output (open drain, 48 V / 100 mA)
GNSS
1× R-SMA connector GPS, GLONASS, BeiDou, Galileo, QZSS
|
|---|
-
Opslag
| Opslag interface | NAND Flash - 512 MB |
|---|
-
Mechanische specificaties
| Afmetingen | 94 × 39 × 90 mm (W × H × D) |
|---|
| Montage | Wall-mount design and optional Din-Rail kits |
|---|
-
Electrische specificaties
| Input range | 9 – 48 VDC (2-pin terminal block) |
|---|
| Power consumption | Idle 3.8W / Average 4.5 W / Maximum 5.5 W (ICR-1642W |
|---|
-
Omgeving specificatie
| Opslag temperatuur | -40°C/+85°C |
|---|
| Operating Temperatuur | -40°C/+75°C |
|---|
| Relatieve luchtvochtigheid | 5~95% (non-condensing) |
|---|
-
Generieke data
|
