DisplayPort
1x DP++: resolution up to 3840x2160 @ 60Hz
HDMI
HDMI: resolution up to 3840x2160 @ 24Hz
VGA
VGA: resolution up to 2048x1536 @ 60Hz
Chipset
Intel® HD Gen 9 Graphics
Belangrijkste eigenschappen
Kenmerken
● 14/13/12th Gen Intel® Core Processors
● 2 DDR5 SODIMM up to 64GB
● Quad Displays:1 DP++ +1 HDM + +1 VGA+ M2A Display (eDP/LVDS/VGA/HDMI)
● Supports 4K resolution
● Multiple Expansion: 1 PCIe x16, 1 M.2 M key, 1 M.2 E Key, 1 M.2 A Key
● Rich I/O: 2 Intel 2.5GbE, 2 COM, up to 6 USB 3.2 Gen2, 2 USB2.0 headers
● Typically supports 10-Year CPU Life Cycle Until Q1’ 38 (Based on Intel IOTG Roadmap), and available for an additional 5 years support under SPS Process
Uitbreidingsmogelijkheden
Uitbreiding slots
PCIe
1x PCIe Gen 5 x16 (Bifircation 1 x16, 2 x8)
M.2
1x M.2 2230 E Key (PCIE Gen3x1 and USB2.0, support Intel® CNVi)
1x M.2 3060 A Key support DFI M2A-display module (opt. MOQ required)
Poorten & Interfaces
LAN poorten
2
Seriele poorten
2
USB 3.x poorten
6
Audio interface
1 x Line-in/Mic-in
Externe I/O
LAN
2x 2.5GHz RJ45
USB
6x USB 3.2 Gen2
Serial
2 x RS-232/422/485
Interne I/O
USB
2x USB 2.0 (2.0mm pitch)
Display
1x M.2 A key, support M2A-Display (eDP/LVDS/VGA/HDMI/DP) by optional
