Processor
| Processor | MIPS 74Kc |
|---|
| Processor serie | Atheros Hornet |
|---|
| Basisfrequentie | 550 MHz |
|---|
-
Geheugen
| Geheugentype | DDR2 |
|---|
| Max geheugen | 64MB |
|---|
-
Belangrijkste eigenschappen
| Kenmerken | • LTE Cat 4 with speeds up to 150 Mbps
• GNSS positioning with geofencing functionality
• Wireless Access Point with Hotspot functionality
• Ignition detection (sleep mode)
• Vibration resistant FAKRA connectors
• Teltonika Remote Management System compatible
|
|---|
-
Poorten & Interfaces
| Apparaat | Routers |
|---|
| mobiel netwerk | 4G (lte) cat4 |
|---|
| wifi | 2.4 GHz (b/g/n) |
|---|
| Externe I/O | • 3 x connection type status LEDs, 1 x WiFi status LED, 5 x connection strength LEDs, 1 x Power LED
• 1 x SIM slots (Mini SIM – 2FF), 1.8 V/3 V, external SIM holder
|
|---|
| Coderingsbeveiliging | • OpenVPN: Multiple clients and server can be running simultaneously, 12 encryption methods
• OpenVPN Encryption: DES-CBC, RC2-CBC, DES-EDE-CBC, DES-EDE3-CBC, DESX-CBC, BF-CBC, RC2-40-CBC, CAST5-CBC, RC2-64-CBC, AES-128-CBC, AES-192-CBC, AES-256-CBC
• IPsec (optional): IKEv1, IKEv2, supports up to 4 x VPN IPsec tunnels (instances), with 5 encryption methods (DES, 3DES, AES128, AES192, AES256)
• GRE (optional): GRE tunnel
• PPTP, L2TP (optional): Client/Server services can run simultaneously
|
|---|
| Wireless Security | • Authentication: Pre-shared key, digital certificates, X.509 certificates
• Firewall: Pre-configured firewall rules can be enabled via web-ui, unlimited firewall configuration via CLI; DMZ; NAT; NAT-T
• Attack prevention: DDOS prevention (SYN flood protection, SSH attack prevention, HTTP/HTTPS attack prevention), port scan prevention ( SYN-FIN, SYN-RST, X-mas, NULL flags, FIN scan attacks)
• WiFi security: WPA2-Enterprise – PEAP, EAP-TLS, TLS, TTLS. AES-CCMP, TKIP, Auto Cipher modes. Client separation
• Mobile quota control: Set up custom data limits for the SIM card
• WEB filter: Blacklist for blocking out unwanted websites, whitelist for specifying allowed sites only
• Access control: Flexible access control of TCP, UDP, ICMP packets, MAC address filter
|
|---|
-
Mechanische specificaties
| Type behuizing | Din Rail |
|---|
| Afmetingen | 131 mm x 79 mm x 18 mm (H x W x D) |
|---|
-
Product eigenschappen
-
Electrische specificaties
| Input range | 9 – 30 VDC (4 pin industrial socket), reverse polarity protection, overvoltage protection up to 60 VDC, surge protection >66 VDC 10us max |
|---|
| Power consumption | < 5W |
|---|
-
Omgeving specificatie
| Operating Temperatuur | -40°C/+75°C |
|---|
| Relatieve luchtvochtigheid | 10% to 90% non-condensing |
|---|
-
Certificeringen
| standaarden | REGULATORY & TYPE APPROVALS
• Regulatory: CE/RED, EAC, RoHS, WEEE
• Operator: AT&T (planned), Verizon (planned)
• Vehicle: ECE R10 (E-mark)
EMI IMMUNITY
• Standards: Draft EN 303 446-1 V1.1.0
• ESD: EN61000-4-2:2009
• RS: EN 61000-4-3:2006, A1:2008 and A2:2010
• EFT: EN 61000-4-4:2004
• CS: EN 61000-4-6:2009
RF
• Standards: EN 300 328 V2.1.1, EN 301 511 V12.5.1, EN 301 908-1 V11.1.1, EN 301 908-2 V11.1.1, EN 301 908-13 V11.1.1, EN 303 413 V1.1.0
SAFETY
Standards: IEC 60950-1:2005 (Second Edition) + Am 1:2009 + Am 2:2013
EN 50665:2017, EN 62311:2008
|
|---|
-
Software support
| Operating systeem | RutOS (OpenWrt based Linux OS) |
|---|
-
Generieke data
| Fabrikant | Teltonika |
|---|
| Ean code | 4779027312057 |
|---|
| Marktsegment | IoT, In-vehicle |
|---|
| Garantie | 24 Maanden |
|---|
| Region (operator) | Europe, the Middle East, Africa, Korea, Thailand, India |
|---|
|
