• Wave-2 802.11ac Dual Band WiFi with speeds up to 867 Mbps
• Gigabit Ethernet with speeds up to 1000 Mbps
• Teltonika Remote Management System compatible
• Bluetooth LE for short range communication
• Quad core ARM Cortex A7 CPU, 717 MHz
• RutOS – easy to use, secure and feature rich Operating System
Poorten & Interfaces
Apparaat
Routers
wifi
5.0 GHz (b/g/n)
bleutooth
Bleutooth LE
LAN poorten
4
USB 2.0 poorten
1
Externe I/O
• 4 x RJ45 ports, 10/100/1000 Mbps
• 1 Digital Input, 1 Digital Output on 4 pin power connector
• Status LEDs: 8 x LAN status LEDs, 1 x Power LED
• 4 pin DC connector
• 2 x RP-SMA for WiFi, 1 x RP-SMA for Bluetooth
• USB A port for external devices
PoE beschikbaar
Ja
POE vermogen
• PoE (passive): Passive PoE. Possibility to power up through LAN port, not compatible with IEEE802.3af and 802.3at standards
Coderingsbeveiliging
VPN
• OpenVPN: Multiple clients and a server can run simultaneously, 12 encryption methods
• OpenVPN Encryption: DES-CBC, RC2-CBC, DES-EDE-CBC, DES-EDE3-CBC, DESX-CBC, BF-CBC, RC2-40-CBC, CAST5-CBC, RC2-64-CBC, AES-128-CBC, AES-192-CBC, AES-256-CBC
• IPsec: IKEv1, IKEv2, with 5 encryption methods for IPsec (DES, 3DES, AES128, AES192, AES256)
• GRE: GRE tunnel
• PPTP, L2TP: Client/Server services can run simultaneously
• Stunnel (planed): Proxy designed to add TLS encryption functionality to existing clients and servers without any changes in the program’s code
• DMVPN: Method of building scalable IPsec VPNs
Opslag
Opslag Capaciteit
256 MB SPI Flash
Mechanische specificaties
Type behuizing
Din Rail
Afmetingen
115 mm x 95 mm x 32 mm (H x W x D)
Montage
• DIN rail (can be mounted on two sides), flat surface placement
Product eigenschappen
Gewicht
357 g
Electrische specificaties
Input range
9 - 50 VDC, reverse polarity protection, voltage surge/transient protection
