DisplayPort & HDMI
1 x DP++
DP++: resolution up to 4096x2304 @60Hz
1 x DP++/HDMI
DP++: resolution up to 4096x2304 @60Hz
LVDS
1 x LVDS/eDP
LVDS: resolution up to 1920x1200 @ 60Hz
eDP: resolution up to 4096x2160 @ 60Hz
extension port
1 x DFI display extension port (DP/ HDMI/VGA available)
Expansion
slots d'extension
PCIe
1 x PCIe x16 (Gen 5)
M.2
1 x M.2 2230 E Key (USB/PCIe x1)
Capacité de stockage
interface de stockage
M.2
1 x M.2 2280 M Key (PCIe Gen3 x1/SATA)
1 x M.2 2242/3042/3052 B Key (SATA/USB 3.2 Gen1/USB 2.0)
SATA
2 x SATA 3.0 (up to 6Gb/s)
RAID 0/1/5/10 (w/ M.2 Key-M/B slot + 2 SATA Conn.)
