Serial Port
2x isolated 3-wire RS232/422/485 Ports
Isolated DIO
4-CH isolated DI
4-CH isolated DO
CAN Ports
2x isolated CAN 2.0 Port, supporting SocketCAN in Linux
Audio
1x 3.5mm MIC-in, Audio-Out
PoE beschikbaar
Nee
Opslag
RAID
0, 1
Opslag interface
SATA
2x hot-swappable 2.5" HDD/SSD Slots, supporting RAID 0/1
M.2
1x M.2 2280 M-Key slot (PCIe)
Mechanische specificaties
Type behuizing
Rack mount
Afmetingen
440mm (W) x 250mm (D) x 88mm (H) (excl. rack-mount bracket)
Montage
Rack-mounting (optional) and wall-mounting (optional)
Product eigenschappen
Gewicht
8.0 kg
Electrische specificaties
Input range
43V~160V DC input (M12 K-coded)
Omgeving specificatie
Opslag temperatuur
-40°C/+85°C
Operating Temperatuur
-40°C/+55°C
Relatieve luchtvochtigheid
10% to 90% , non-condensing
Certificeringen
certificaten
Vibration
EN 50155:2021/ IEC 61373, Category I, Class B - Body mounted
Shock
EN50155:2021/ IEC61373, Category I, Class B - Body mounted
EMC
EN50121 (EN50155 EMC)
CE/FCC Class A, according to EN55032 & EN55035
EN50155
All mandatory sections of EN50155:2021 (110V)
Interruptions of voltage supply Class S3: 0V/ 20ms
Supply change-over
Class C2: 0V/ 30ms
Voltage withstand test: 1500V DC
EN45545
EN45545-2 (Fire protection on railway vehicles)
Software support
Operating systeem
Microsoft Window 10 LTSC 2021 (x64) Ubuntu 20.04.5 LTS, 22.04 LTS, 22.04.1 LTS or other distribution with kernel version ≥ 5.15 */** (Notes please see manual)
