8 Port full gigabit PoE ethernet switch

SKU:

UTP3-GSW0802-TP120

Fabrikant:

Utepo

Hersteller : Utepo
Schaltertyp : Unmanaged Switch

Lokaal op voorraad

Zur Vergleichsliste hinzufügen

Details

Weitere Informationen

Downloads

Weitere Informationen

Wesentliche Merkmale

Hauptmerkmale

• Main Function: Provide 8*10/100/1000Base-T Ethernet ports(PoE) , 2* 10/100/1000BASE-T Ethernet ports
• Compliance with standards: IEEE802.3 、IEEE802.3u、IEEE802.3ab、IEEE802.3X、IEEE802.3af/at
• PoE Power Supply: With 8x gigabit PoE RJ45 ports, each port supports max. 30W PoE output, whole machine reaches 120W PoE power output
• One-key CCTV: Quickly achieve isolation among downlink ports vis dial switch, effectively restrain network storm, improve network feature
• Protection: Support 6KV surge immunity, EFT testing standard
• Operation Environment: Support -10℃~45℃ wide-temperature
• Operation: Plug&play, convenient to use, support desktop, wall-mounted installations

Ports & Schnittstellen

Schaltertyp	Unmanaged Switch
LAN-Anschlüsse	8
Switch Architecture	• Switch Capacity: 20Gbps
Übertragungsrate	• Downstream Ports: 8* 10/100/1000Base-T (PoE) • Uplink Ports: 2x 10/100/1000Base-T Ethernet Ports
PoE verfügbar	Ja
PoE-Leistung	• PoE Standard: 802.3af/at(PSE) • PoE Power Output: 54V DC , 30 watts max • PoE Budge: 120 watts max

Mechanische Spezifikation

Abmessungen 200mm (l) ×101.8mm (w) ×27mm (h)
Produkt Merkmale

Gewicht 500g
Umgebungsbedingungen

Lagertemperatur • -40℃~85℃
Relative Luftfeuchtigkeit • Humidity (Non-condensing) 5%-95%
Allgemeine Daten

Hersteller Utepo
Gewährleistung 24 Monate

Downloads

Handbuch	User%20Manual%20UTP3-GSW0802-TP120%20V1.0.pdf
Datenblatt	UTP3-GSW0802-TP120_Datasheet_VER2.0.pdf

204,68 € 172,00 €
