Intel Xeon CPU, up to 16 cores
Up to 128GB ECC DDR4
Two 10Gbit ports
Expansions for GPGPU, RAID...
Real SWaP-C
Fanless and flexible IP67 solution
19" MIL housing available
Erweiterungsmöglichkeiten
Erweiterungssteckplätze
mPCIe
4 x mPCIe PCI Express Gen2 x1
PCI/104-Express 1 x PCIe x8
PCIe x16 1 x PEG graphic expansion
SATA 2 x mSATA / 2 x m.2 Key M ports
RAID optional RAID controller board with on-board memory and flash,
up to 8 x SAS/SATA ports, RAID 0/1/5/10 support
Ports & Schnittstellen
Watchdog-Timer
configurable granularity 10 ms, 1 s or 1 minute, results in a timeout from 2.5 seconds up to 4 hours
LAN-Anschlüsse
2
Serielle Schnittstellen
2
USB 2.0-Anschlüsse
4
Mechanische Spezifikation
Abmessungen
TBD - to customer specifications custom housings and connectors available
Elektrische Spezifikation
Eingangsbereich
19 - 36 VDC input range, ESD and EMC protected power input (redundant capability)
