DisplayPort
1x DisplayPort, Type-C waterproof connector, supporting resolution up to 4096 x 2304
1x DisplayPort, reserved Port, supporting resolution up to 4096 x 2304
VGA Ports
1x VGA Port, supporting resolution up to 1920 x 1200, via M12 connector, A-coded, 17-Pins
Chipsatz
Intel UHD Graphics 770
Wesentliche Merkmale
Hauptmerkmale
Features
• Supporting Intel 14th/13th/12th Gen Core Processor, up to 24C/32T, 35/65W TDP CPU
• Affordable IP66-rated waterproof and dustproof design
• Up to 128GB DDR5-4800 SO-DIMM RAM support
• 3x 2.5GbE Ports, 1x GbE Port, via M12 X-coded connectors, optional with 802.3at PoE+
• 1x USB3.2 Type-C waterproof connector, support Alt. Mode for Displayport and USB3.2 dual output
• Wide-temperature fanless operation: -25°C/70°C
• 8V~35V DC wide-range input, built in ignition power control
