Mini PCIe 2 (1* half size, 1* full size share with mSATA)
mSATA 1 (full size, share with Mini PCIe)
PCIe
1 (PCIex16 slot), Support NVMe
SIM Card slot
1 slot
Ports & Schnittstellen
GPIO-Schnittstelle
1 x GPIO (8 bit)
SATA-Schnittstelle
5 x SATAIII
Watchdog-Timer
256 segments (10sec ~ 255min)
LAN-Anschlüsse
2
Audio-Interface
3 (Line-In, Line-Out, MIC)
Externe I/O
1 x VGA
1 x HDMI
1 x DisplayPort
2 x Ethernet
4 x USB 3.1 (Gen. 2) & 2 x USB3.1 (Gen. 1)
1 x Audio 3 (Line-In, Line-Out, MIC)
2 x (COM 1/2 support RS232/422/485)
Interne I/O
4 x USB3.1 (Gen. 1), 2 x USB 2.0
1 x PS/2
1 x LVDS / inverter
4 x Serial
5 x SATAIII
1x SIM card slot
2 x mPCIe (1 * half size, 1 * full size share with mSATA)
1 x mSATA (full size share with mPCIe)
1 x GPIO (8 bit)
1 x Chassis intrusion
1 x Audio Header
1 x SMBUS
1 x AT mode
1 x TPM 2.0
