• Intel® Celeron® Bay Trail J1900 quad-core processor
• 1x PCI/PCIe expansion with compact size
• Dual storage with 1x mSATA and 1x SATA
• Dual independent display via VGA and DVI connectors
• Optional Auxiliary I/O for PWM and Encoder signals
• 2x RS-232/422/485 and 2x RS-232
• 8V to 35V wide-range DC input
• Rugged, wide temperature range from -25° to 70°C operation
Erweiterungsmöglichkeiten
Erweiterungssteckplätze
1x PCIe x4 slot @ 1-lane PCIe 2.0 signal in Cassette (Nuvo-2500E)
Ports & Schnittstellen
LAN-Anschlüsse
2
Serielle Schnittstellen
2
USB 2.0-Anschlüsse
3
USB 3.x-Anschlüsse
1
Audio-Interface
Due to component scarcity, no audio on this device
Externe I/O
1x DVI-D output via DVI-I
supporting resolution up to 2560 x 1600
2x RS-232 (COM3 & COM4)
1x DB37 connector
1x DB-37 female connector
4x DI and 8x DO, 6x PWM, 1x encoder and 2x voltage inputs are available as an option of MAIO
Interne I/O
1x full-size mini PCI Express socket with USIM holder (PCIe x1 Gen2 and USB2 signal)
1x full-size mini PCI Express socket (USB signal)
Speicher
Speicherschnittstelle
1x Internal SATA port for 2.5” HDD/ SSD installation
1x internal half-sized mSATA (SATA + USB)
Mechanische Spezifikation
Gehäusetyp
Kompakt lüfterlos
Abmessungen
205 mm (W) x 145 mm (D) x 73 mm (H)
Montage
Wall-mount (standard) or DIN-rail mount (optional)
Produkt Merkmale
Gewicht
2.3 kg
Elektrische Spezifikation
Eingangsbereich
8~35V DC
Umgebungsbedingungen
Lagertemperatur
-40°C /+85°C (For sub-zero operating temperature, a wide temperature HDD drive or Solid State Disk (SSD) is required.)
