VGA Ports
1x VGA Port, DB15, supporting up to 1920x1200
Chipsatz
Intel UHD/HD Graphics, depending on CPU
Wesentliche Merkmale
Hauptmerkmale
Features
• Intel 12th/13th/14th Gen Support
• 2x GbE Lan Ports, 2x USB3.2 Gen2, 6x USB3.2 Gen1, 1x USB2.0 internal
• 2x RS-232/422/485 DB9, support auto flow control
• VGA & HDMI Video Output
• 1x M.2 2280 M-Key (PCIe Gen4x4), 1x 2.5" HDD/SSD Support, 1x mSATA
• 9V-36V DC inpot power range
• IP40 dust proof for deployment in harsch environments
• Wide Operating Temperature: -20°C/+60°C
• Support FlexIO and iDoor technology. Flexible IO Support
• Support Advantech i-modules
Erweiterungsmöglichkeiten
Erweiterungssteckplätze
Mini PCIe Slot
1x miniPCIe Slot
1x miniPCIe / mSATA
Ports & Schnittstellen
LAN-Anschlüsse
2
Serielle Schnittstellen
2
USB 2.0-Anschlüsse
1
USB 3.x-Anschlüsse
6
Audio-Interface
1x Line-Out, 1x Line-In
Externe I/O
Ethernet Ports
2x GbE Port (1x i219LM, 1x i210T)
USB Ports
4x USB3.2 Gen1
4x USB2.0
Serial Ports
2x RS-232/422/485 DB9, support auto flow control
Optional: 4x RS-232
