Intel HDAudio signals, available on a 1 mm header, sound card (HDSOUND-1) is available
Externe I/O
Graphics Interfaces
Display Port (DP) up to 4096x2160 (DP) and DVI-D (LVDS / eDP up to 1920 x 1200 optional)
Triple display capable, ESD protected. Gen3 PCIe port x16 (PEG) for graphic card
USB
8x USB 3.1 ports, supports USB keyboards and mice as legacy devices
4x additional internal USB2.0 ports
LAN
AMT / vPro support*, optional up to 5 LAN ports
Serial Ports
4x full modem RS232/422/485 ports, ESD protected and isolated on external DB9 connectors
HDAudio
Intel HDAudio signals, available on a 1 mm header, sound card (HDSOUND-1) is available
Speicher
Speicherschnittstelle
SATA
2x SATA 3.0 ports
mSATA
2x mSATA Full-Mini Card combo socket with SATA 3.0 & USB 2.0
m.2 1x NVMe or SATA SSD
Mechanische Spezifikation
Gehäusetyp
Kompakt lüfterlos
Abmessungen
270 x 162 x 63/83/120mm
Montage
DIN-RAIL
Produkt Merkmale
Gewicht
2,2kg
Elektrische Spezifikation
Eingangsbereich
10 - 36 VDC input range, ESD and EMC protected power input (optionally up to 110VDC) Protection against: up to -36 VDC over voltage, reverse polarity, up to 150V load dump
Leistungsaufnahme
5-65 Watt (Enhanced Intel Speed Step Technology)
Zündsteuerung / Ignition-Control
Combinded power button and ignition input, specifically for vehicles
Umgebungsbedingungen
Lagertemperatur
-45°C up to +85°C
Betriebstemperatur
-20°C/+60°C
Zertifizierung
Normen
The PIP40 Family is designed to meet or exceed the most common standards. Particular references are:
EMC
EN 55022, EN 55024, EN 61000, MIL-STD-461E
Shock & Vibration
EN 60068
Environmental & Safety
EN 50155, MIL-STD-810G, EN 60601, EN 60950
