VGA
1x M12 12-pin for VGA with waterproof cover and chain
Main features
Characteristics
USB
1 x M12 8-pin for 2 x USB 2.0 for Touch Control with waterproof cover and chain
Functional Keypad
1 x M12 8-pin for OSD Cable & External OSD BOX with waterproof cover and chain
Features
• SUS 316 Stainless Steel
• Total IP66 Grade with M12 Waterproof Connector
• Wide range DC 9~36V Power Input
• Support Panel Mount & VESA Mount
• Support Projected Capacitive Touch
• Full Flat Bezel and Fanless Design
• Stainless Steel OSD Function Key
• ATEX/IECEx Zone2, Zone22 and C1D2/C2D2/C3 Certified
Mechanical specifications
Dimensions
399 x 324 x 70 mm
Casing
Total IP66
Mounting
VESA mount 100 x 100, Panel mount (option)
Product features
Weight
8.5kg
Electrical specifications
Input range
DC 9~36V
Power consumption
AEx-115P: 17W
Environmental specification
Storage temperature
-30°C/+70°C
Operating Temperature
-20°C/+60°C
Certificates
certificates
Certificates
CE / FCC Class A
ATEx / IECEx Zone2 Ex ec ic IIC T4 Gc
ATEx / IECEx Zone22 Ex tc IIIC T135°C Dc
Class I, Division2, Group A,B,C,D,T4
Class II, Division2, Group F,G, T135°C
Class III
ANSI/ISA 12.12-01-2013
CSA Std., C22 No213-1987
