VGA
1 x VGA (resolution up to 2560x1600@60Hz)
DisplayPort
1 x DP (Opt. in rear side, resolution up to 4096x2160 @ 60Hz)
Chipset
Intel® UHD Graphics for 10th Gen Intel® Processors
Expansion
expansion slots
M.2
1 x M.2 2230 (USB/PCIe)
1 x M.2 3042/3052 (USB 3.0/PCIe) with dual SIM
Ports & Interfaces
LAN Interface
3
USB 2.0 ports
2
USB 3.x ports
4
External I/O
Lan
2 x GbE (RJ-45) (configuration options)
1 x 2.5GbE TSN RJ45
Serial
2 x RS232/422/485
2 x COM(Isolated),
Digital I/O
6 bit DI+ 6 bit DO(Isolated)
USB
2 x USB 2.0
4 x USB 3.1
Mechanical specifications
Dimensions
72 x 172 x 118.2 (mm)
Mounting
Wall/DIN rail mount
Product features
Weight
1.6kg
Electrical specifications
Input range
9~36V
Environmental specification
Storage temperature
-40°C/+85°C
Operating Temperature
0°C/+60°C
relative air humidity
10 to 90% RH (non-condensing)
Certificates
standards
ShockOperating:
3G, 11ms
Non-Operating:
5G, 11ms
VibrationOperating:
Random 5~500Hz, IEC68-2-64 (3G)
Non-Operating:
Sine 10~500Hz, IEC68-2-6 (3G)
