Features
• Supports Intel® Core™ Ultra 200 Series 24C/24T 35W/65W LGA1851 CPU
• Rugged, -25°C/+70°C temperature operation range
• Up to 5x 2.5GbE Ports
• 1x GigE Port, optional PoE+, supporting 9.5 KB jumbo frame
• Up to 8x USB 3.2 Ports
• 4-CH isolated DI and 4-CH isolated DO
• 1x optional 10GbE Port
• Expansion Cassette for PCIe add-on card
• MezIO® interface for easy function expansion
Expansion
expansion slots
miniPCIe
2x mini PCI Express slots
MezIO
1x MezIO® expansion port for Neousys MezIO® modules
Ports & Interfaces
LAN Interface
6
USB 3.x ports
8
Audio interface
1x 3.5 mm MIC-in, Audio-Out
External I/O
Ethernet Ports
5x 2.5GbE Ports and 1x GbE Port (Nuvo-11006E/DE/LP), with screw-lock
USB
8x USB 3.2 Ports (Nuvo-11006LP/E/DE)
Serial Port
2x software-programmable RS-232/422/485 Ports
2x 3-wire RS-232 Ports
Isolated DIO
4-CH isolated DI and 4-CH isolated DO
Audio
1x 3.5 mm MIC-in, Audio-Out
PoE available
Yes
POE capability
PoE Capability
Port 3~6: optional IEEE 802.3at PoE+ PSE
Total power budget: 100W
Storage
Storage Interface
SATA
1x hot-swappable 2.5" HDD tray (7mm HDD/ SSD)
1x internal 2.5" SATA port, supporting RAID 0/ 1 (Nuvo-11000LP)
M.2
1x M.2 2280 M-Key Slot (PCIe) for SSD (Nuvo-11006E/DE/LP)
Mechanical specifications
Dimensions
240mm (W) x 225mm (D) x 79mm (H) (Nuvo-11000LP series)
Mounting
Wall-mount (standard) or DIN-rail mount (optional)
Product features
Weight
3.36 kg (Nuvo-11000LP Series)
Electrical specifications
Input range
8V~48V DC input, 3-pin
Environmental specification
Storage temperature
-40°C/+85°C
Operating Temperature
-25°C/+70°C
relative air humidity
10% to 90% , non-condensing
Certificates
standards
Vibration
MIL-STD-810H, Method 514.8, Category 4
Shock
MIL-STD-810H, Method 516.8, Procedure I
EMC
CE/FCC Class A, according to EN 55032 & EN 55035
