guide rail I/O, D80mm, yellow, bottom
Please contact us for the delivery time.
Details
More Information
Downloads
More Information
-
Product features
| Product type | Guide rails |
|---|
| Product group | Keyable guide rails for I/O subracks |
|---|
| Version | Installation bottom, for PCB-depth 80 mm |
|---|
| Handle hole | No |
|---|
| General product information | For rear I/O assemblies
Guide rails 4 HP, keyable to IEEE 1101.10. Prepared to accommodate a ground contact for assembly of a plug-type connection. - For 1.6 – 2.0 mm nominal thickness
- For 80 mm deep PCBs
- Chambers for the installation of keys
- Option of installing ESD contacts to discharge static charges
- Narrow design for maximum air flow
- For CPCI or VME applications
Material: Polycarbonate, base material to UL 94-V0
Note: Only for use in conjunction with type IV, IVs, VII injector/extractor handles. |
|---|
| Weight | 3,96 gr. |
|---|
-
General data
| Manufacturer | HEITEC AG |
|---|
| Ean code | 4250558909898 |
|---|
| Warranty | 12 Months |
|---|
|
