DisplatPort
1 x DP++
DP++: resolution up to 4096x2304 @60Hz
DisplatPort/HDMI
1 x DP++/HDMI
DP++: resolution up to 4096x2304 @60Hz
LVDS/eDP
1 x LVDS/eDP
eDP: resolution up to 4096x2160 @ 60Hz
LVDS: resolution up to 1920x1200 @ 60Hz
Extension
1 x DFI display extension port (DP/ HDMI/VGA available)
Expansion
expansion slots
M.2
1 x M.2 2280 M Key (PCIe Gen4 x4/SATA)
1 x M.2 2242/3042/3052 B Key (PCIe Gen3 x1/SATA/USB 3.2 Gen2/USB 2.0)
Ports & Interfaces
LAN Interface
3
USB 2.0 ports
4
USB 3.x ports
2
Audio interface
1 x Front Audio Header
External I/O
Lan
1 x Intel® I225LM PCIe(10/100/1000/2.5G speeds)
1 x Intel® I219LM PHY(10/100/1000 speeds) (support vPro/AMT)
1 x Intel® I210AT PCIe(10/100/1000 speeds)(Opt.)
Serial
2 x RS-232/422/485
USB
4 x USB 2.0 (2.54mm pitch)
2 x USB 3.2 Gen1
